Series |
BP/H |
Working principle |
Pressurized |
Types |
120BP/H-6TF |
160BP/H-8TF |
Collector tubes |
Heat pipe evacuated tube collector |
Tube dimension |
Ø100 x 2000mm |
Quantity of tubes |
6 |
8 |
Absorber area |
1 m² |
1.4 m² |
Capacity of tank |
120 L |
160 L |
Inner material of tank |
High quality 2.0 mm thick alloy steel plate with quartz enamel coating, close circuit |
Cover material of tank |
Colored steel plate, 0.5mm thick |
Side cover material of tank |
PP |
Insulation |
50 mm polyurethane foam |
Reflector |
High quality empaistic aluminum plate, 0.4 mm thick |
Support frame (15/30/45°) |
P-- Angle steel with spurted plastic coating;
H---Aluminum alloy |
Electric heater |
No |
Efficiency |
>50% |
Operation |
Thermosiphon close circuit system pressure up to 4 bar |
Gross weight with water |
190kg |
260kg |
Available range |
3~4 people |
4~5 people |
